PRODUCTS
1200℃ Tube Furnace
1200℃ Series Lab tube Furnace
Inner Chamber
Quartz Tube
Introduction
The split sintering tube furnace hinge design permits easy process tube installation, fast cooling, and overall ease of operation. These furnaces come equipped with energy-efficient heating elements that provide superior temperature uniformity, fast heat-up and cooldown and require little or no maintenance.
Main Features
Tmax 1200 °C
High quality ceramic fiber block
High level HRE heating wire embedded in the ceramic chamber
Heating from all sides for an optimal temperature uniformity
Thermocouple type N (1260 °C)
Temp Controller Shimaden SRS13A (4 programs with each 8 segments)
Available for gas purging
Optional Accessories
Quartz Tube
Digital Vacuum Gauge
Vacuum Pump
Built-in RS485 port and USB adaptor as optional setting for comptur control
|
Model No. |
TMax (℃) |
Inner Chamber Dimensions （mm） |
Tube Length （mm） |
Power Supply |
|
|
OD |
L |
||||
|
STG-40-12 |
1200 |
40 |
300 |
800 |
1.8KW/1-Phase |
|
STG-60-12 |
1200 |
60 |
300 |
800 |
2.6KW/1-Phase |
|
STG-80-12 |
1200 |
80 |
300 |
800 |
2.6KW/1-Phase |
|
STG-100-12 |
1200 |
100 |
300 |
800 |
2.6KW/1-Phase |
Note:Chamber Size could be customized as per requests
1400℃ Tube Furnace
1400℃ atmosphere tube furnace
Tube Furnace wiht Ceramic Tube
KF Fanlages
Silicon Carbide Heaters
Main Features
Tmax 1400 °C
High quality ceramic fiber block
High level SiC vertically distribute in two sides
Heating from all sides for an optimal temperature uniformity
Thermocouple type S (1460 °C)
Temp Controller Shimaden SRS13A (4 programs with each 8 segments)
Available for gas purging
Optional Accessories
Alumina Tube
Digital Vacuum Gauge
SiC heaters
Vacuum Pump
Built-in RS485 port and USB adaptor as optional setting for comptur control
|
Model No. |
TMax (℃) |
Inner Chamber Dimensions （mm） |
Tube Length （mm） |
Power Supply |
|
|
OD |
L |
||||
|
STG-40-14 |
1400 |
40 |
300 |
800 |
2KW/1-Phase |
|
STG-60-14 |
1400 |
60 |
300 |
800 |
3KW/1-Phase |
|
STG-80-14 |
1400 |
80 |
300 |
800 |
4KW/1-Phase |
|
STG-100-14 |
1400 |
100 |
300 |
800 |
5KW/1-Phase |
Note:Chamber Size could be customized as per requests
1700℃ Lab Tube Furnace
1700℃ ceramic tube furnace
MoSi2 Rod Heating Elements
Introduction
The 1700C degree wire annealing tube furnace is often customized in order to precisely meet the user’s requirements on the sintered material. The furnace adopts U type MoSi2 rods as heaters. Vertically distributed in two sides, ensures an improved temperature gradient. Resistance of a MoSi2 heating element does not change under normal use, and you can mix new and old elements together.
Main Features
Tmax 1700 °C
1800 grade ceramic fibre as insulation material
High quality MoSi2 rods
Heating from two sides
Thermocouple type B (1760 °C)
Temp Controller Yudian 518P (32 segments)
Optional Accessories
Exhaust chimney
Extra set of Ceramic Tube
Shimaden FP93 Controller
Model No. | TMax (℃) | Inner Chamber Dimensions （mm） | Tube Length （mm） | Power Supply | |
OD | L | ||||
STG-40-17 | 1700 | 40 | 300 | 800 | 3KW/1-Phase |
STG-60-17 | 1700 | 60 | 300 | 800 | 4KW/1-Phase |
STG-80-17 | 1700 | 80 | 300 | 800 | 5KW/1-Phase |
STG-100-17 | 1700 | 100 | 300 | 800 | 5KW/1-Phase |
Note:Chamber Size could be customized as per requests
